12’ MODEL FW151
FW151: Advanced Features for the Avid Explorer
The FW151 steps up the game with a steering helm, extensive storage lockers, and a self-bailing motor well. Its large fuel tank extends your adventures, allowing you to explore farther and with greater confidence.
Features:
Open hull
Open bow storage (fuel tank or anchor)
Perfect fit for swim platform or upper deck stored tenders on 14M/50ft or larger power and sail yachts
Excellent small fishing platform
Four davit lifting points
Stern grab handles
60 liter/15 gallon fuel tank.
Electronics Systems:
Auto 500gph bilge pump
Navigation/safety lights, 12v power point and usb charger, additional aux switches.
Group 24 battery and disconnect.
Fuse panel with bus bar.
Fuel gauge
NFB helm with viper steering wheel.
Specifications:
Hull Length: 3.84M/12'7"
Beam:2.03M/6'8"
Dry Weight: 315kg/693lbs
USCG Load Capacity/Persons: 657kg/1450lbs gross, 6 persons
Max HP/Outboard Weight: 70hp, 136kg/300lbs
Recommended Prop Pitch: 10x12 to 10x16
Hull Thickness
Bottom: 4mm/.156"
Pontoons: 2.5mm/.100"
Transom: 3mm/.125
Sheet: 5000 Series
Extrusions: 6000 Series
Steering Control: Tiller helm/console
